Designer Shaw Main Area 297 Hull Speed 7.29
Model # 78 For Tri 363 SA/D 17.4
First Year 1985 I 47.1 D/L 258
Last Year 1990 J 15.4 BR 39%
LOA 36.5 P 41.0 L/B 2.97
LWL 29.6 E 14.5 LWL /B 2.41
Beam 12.3 Eng D OR 19%
Disp 15,000/15,850 CSF 2.00
Draft 6.5/4.2-8.3 MCR 25.7
Sail Area 660 M/F 0.82
Ballast 5,800/6,550 PHRF 129
Info on Design Ratios
1986
