Pearson 390
Return to Pearson Info . . . | 386 | 390 | 39

Designer    Shaw    Main Area  353   Hull Speed  7.77
First Year  1972    For Tri    364   SA/D        15.2
Last Year   1973    I         46.7   D/L          241
LOA         39.0    J         15.6   BR           37%
LWL         33.7    P         47.0   L/B         3.00
Beam        13.0    E         15.0   LWL /B      2.59
Disp      20,600    Eng          D   OR           14%
Draft    4.3/7.6    Water      300   CSF         1.90
Sail Area    716    # Built    40?   MCR         29.4
Ballast    7,600                     M/F         0.97
Info on Design Ratios
A letter from Bill Shaw decscribing the 390/419/424/422.

1972

1972
